10.HQ24

10.HQ24

share

10.HQ24

  • Detail
  • Parameters





d

(mm)

D1
D2
D3
L1
L2
10
21
17
20.05
23.9
8.6
12
23
19
21.70
23.9
8.6
14
25
21
24.00
26.4
8.6
16
27
23
26.65
26.4
8.6
18
33
27
30.35
27.5
10.0
20
35
29
33.50
27.5
10.0
22
37
31
33.55
27.5
10.0
24
39
33
38.00
30.0
10.0
25
40
34
39.50
30.0
10.0
28
43
37
42.20
32.5
10.0
30
45
39
43.95
32.5
10.0
32
48
42
46.00
32.5
10.0
33
48
42
46.00
32.5
10.0
35
50
44
49.10
32.5
10.0
38
56
49
53.00
34.0
11.0
40
58
51
56.00
34.0
11.0
43
61
54
58.80
34.0
11.0
45
63
56
61.20
34.0
11.0
48
66
59
64.00
34.0
11.0
50
70
62
66.00
34.5
13.0
53
73
65
70.65
34.5
13.0
55
75
67
71.65
34.5
13.0
58
78
70
79.60
39.5
13.0
60
80
72
80.40
39.5
13.0
63
83
75
81.50
39.5
13.0
65
85
77
84.30
39.5
13.0
68
90
81
89.65
37.2
15.3
70
92
83
89.65
44.7
15.3
75
97
88
96.80
44.7
15.3
80
105
95
104.00
44.3
15.7
85
110
100
107.95
44.3
15.7
90
115
105
111.10
49.3
15.7
95
120
110
119.00
49.3
15.7
100
125
115
124.00
49.3
15.7



Type
Elastomeric bellow mechanical seal
Replacement
Vulcan 24, AES P03,  Crane 521，Burgmann MG912/D1-G60，Roten 52/L4K，Flowserve 240, Latty T400
Temperature
-30℃ to +200℃
Pressure
≤1.0Mpa
Speed
≤10m/s
Material
V,Q1,Q2,U2,U1,B,A,P,E,V,F,G
