08.HQ21/HQ21T

08.HQ21/HQ21T

share

08.HQ21/HQ21T

  • Detail
  • Parameters





   Size    (inch)

d

D1

D3

(HQ21)

D3 T

(HQ21T)

L1
L2
0.500
12.7
25.40
24.0
22.8
20.62
7.95
0.625
15.8
31.75
26.7
26.7
22.23
10.31
0.750
19.1
34.93
31.2
30.4
22.23
10.31
0.875
22.2
38.10
33.5
33.4
23.80
10.31
1.000
25.4
41.28
43.2
39.3
25.40
11.10
1.125
28.6
44.45
46.5
42.0
26.97
11.10
1.250
31.7
47.63
49.5
45.8
26.97
11.10
1.375
34.9
50.80
52.7
49.3
28.58
11.10
1.500
38.1
53.98
56.0
52.8
28.58
11.10
1.625
41.2
60.33
62.2
55.5
34.93
12.70
1.750
44.4
63.50
66.0
61.0
34.93
12.70
1.875
47.6
66.68
66.0
64.0
38.10
12.70
2.000
50.8
69.85
73.0
66.0
38.10
12.70
2.125
53.9
76.20
73.5
71.5
42.85
14.27
2.250
57.1
79.38
79.6
79.6
42.85
14.27
2.375
60.3
82.55
82.0
79.6
46.05
14.27
2.500
63.5
85.73
85.0
81.5
46.05
14.27
2.625
66.6
85.73
88.5
84.6
49.20
15.88
2.700
69.8
88.90
92.7
90.0
49.20
15.88
3.000
76.2
98.40
102.0
96.8
52.37
15.88



d

(mm)

D1
D3
(HQ21)
D3T
(HQ21T)
L1
L2
12.7
25.40
24.0
22.8
20.62
7.95
15.8
31.75
26.7
26.7
22.23
10.31
19.1
34.93
31.2
30.4
22.23
10.31
22.2
38.10
33.5
33.4
23.80
10.31
25.4
41.28
43.2
39.3
25.40
11.10
28.6
44.45
46.5
42.0
26.97
11.10
31.7
47.63
49.5
45.8
26.97
11.10
34.9
50.80
52.7
49.3
28.58
11.10
38.1
53.98
56.0
52.8
28.58
11.10
41.2
60.33
62.2
55.5
34.93
12.70
44.4
63.50
66.0
61.0
34.93
12.70
47.6
66.68
66.0
64.0
38.10
12.70
50.8
69.85
73.0
66.0
38.10
12.70
53.9
76.20
73.5
71.5
42.85
14.27
57.1
79.38
79.6
79.6
42.85
14.27
60.3
82.55
82.0
79.6
46.05
14.27
63.5
85.73
85.0
81.5
46.05
14.27
66.6
85.73
88.5
84.6
49.20
15.88
69.8
88.90
92.7
90.0
49.20
15.88
73.0
95.20
95.0
92.0
52.37
15.88
76.2
98.40
102.0
96.8
52.37
15.88



d
(inch)
D1
D3
(HQ21)
D3T
(HQ21T)
L1
L2
0.500
1.000
0.945
0.897
0.812
0.312
0.625
1.250
1.053
1.053
0.875
0.405
0.750
1.375
1.230
1.201
0.875
0.405
0.875
1.500
1.319
1.319
0.937
0.405
1.000
1.625
1.703
1.547
1.000
0.437
1.125
1.750
1.831
1.654
1.062
0.437
1.250
1.875
1.949
1.803
1.062
0.437
1.375
2.000
2.077
1.941
1.125
0.437
1.500
2.125
2.205
2.078
1.125
0.437
1.625
2.375
2.451
2.185
1.375
0.500
1.750
2.500
2.598
2.402
1.375
0.500
1.875
2.625
2.598
2.520
1.500
0.500
2.000
2.750
2.874
2.598
1.500
0.500
2.125
3.000
2.894
2.814
0.688
0.562
2.250
3.125
3.133
3.133
1.688
0.562
2.375
3.250
3.228
3.133
1.812
0.562
2.500
3.375
3.346
3.209
1.812
0.562
2.625
3.375
3.484
3.331
1.937
0.625
2.750
3.500
3.652
3.543
1.937
0.625
2.875
3.750
3.740
3.622
2.062
0.625
3.000
3.875
4.016
3.811
2.062
0.625




Type
Elastomeric bellow mechanical seal
Replacement
Crane 21 with N seat，AES P04/P04T, Vu1can 11，Roten 21A，Flowserve 110
Temperature
-30℃ to +200℃
Pressure
≤1.0Mpa
Speed
≤13m/s
Material
V,Q1,Q2,U2,U1,B,A,P,E,V,F,G
